Germany Munitionspanzer 38(t) Ausf K Ordnance classification - SdKfz 138

Tweet The Munitionspanzer 38(t) Ausf K based on the existing Czech LT Vz 38 and was in use from 1944 to 1945. General Details Specifications Operational Date(s) 1944 - 1945 Ordnance classification SdKfz 138 Quantity Produced 321 Weight unknown Crew 2 M.G's small 1 M.G's large(>10mm) n/a Length 4.95 mtr Width 2.15 mtr Height 2.47 mtr Engine Details/Performance Max Road Speed 22 mph Max Cross Country Speed 10 mph Range Road 119 miles Range Cross Country unknown Fuel Type Petrol Fuel Capacity unknown Horse Power 125 hp Power/Weight unknown General Information The Munitionspanzer 38(t) Ausf K based on the existing Czech LT Vz 38 and was in use from 1944 to 1945. It was armed with 1 light machine gun. Armour Details Turret Front n/a Side n/a Rear n/a Top n/a Superstructure Front 10mm @ 67° (26mm) Side 10mm @ 15° (10mm) Rear 10mm @ 0° (10mm) Top 8mm @ 90° (8mm) Hull Front 20mm @ 15° (21mm) Side 15mm @ 0° (15mm) Rear 10mm @ 41° (13mm) Top 10mm @ 90° (10mm) Armour (x)mm @ (y)° (Effective mm @ 0°) Effective Armour - Maximum 26 mm - Minimum 10 mm

Hit probability is based on a static 2 x 2.4 metre panel at 0 degrees(vertical) at the range specified.

The data that has been used to create these records has come from Wikipedia, The Lone Sentry, The Bundes Archive and numerous books and websites that have provided the detailed information that has not been available anywhere else. The information we use to calculate the penetration tables, flight times and the hit probability comes from the Gun Calibre, the Shell Mass(Kg) and the muzzle velocity, plus range reductions to allow for gravity and wind resistance. This calculation originally came from a pre-war Krupp calculation which has been modified, and seems to fit the actual test results.
